MicroTrace

µTrace®

技术数据

µTrace®的技术数据

本产品

产品 PowerDebug X51 + PowerTrace PowerDebug E40 +CombiProbe 2
µTrace® for Cortex-M µTrace® for RISC-V
PC Interface
USB 3.2 Gen 1, Type C and 2.5 Gigabit Ethernet USB 3.2 Gen 1, Type B USB 3.2 Gen 1, Type B USB 3.2 Gen 1, Type B 电压范围 from 0.4 to 5.0 V 1
from 1.2 to 5.0 V 5 1.2 to 5.0V
1.2 to 5.0V
调试协议 JTAG, cJTAG, SWD, DAP and many more JTAG, cJTAG, SWD, DAP and many more JTAG，cJTAG，SWD
JTAG，cJTAG，SWD Extension connectors
PodBus and PodBus Express
PodBus
N/A
N/A
跟踪端口宽度（Max.）。 32 parallel lines2 or 8 serial lanes3
two ports with 4 parallel lines
4 parallel lines
4 parallel lines 跟踪记录速度（Max）。 600+ Mbit/s per parallel line2 22.5 Gbit/s per serial lane3
400 Mbit/s per line
400 Mbit/s per line
400 Mbit/s per line
跟踪流性能4（Peak / Average）。 高达 2 400 / 400 MByte/s up to 200 / 140 MByte/s
up to 200 / 140 MByte/s
up to 200 / 140 MByte/s
跟踪内存大小 8 GByte 512 MByte 256 MByte 256 MByte 可选logic analyzer 和能量曲线 Mixed Signal Probe
Mixed Signal Probe
Mixed-Signal Probe Mixed-Signal Probe 触发连接器 4.4V out / 3.3V in (5V tolerant)
4.4V out / 3.3V in (5V tolerant)
3.3V out / 3.3V in (5V tolerant)
3.3V out / 3.3V  in (5V tolerant)
Supported Architectures1
Over 150 microprocessor architectures
Over 150 microprocessor architectures
Arm Cortex-M RISC-V 32-bit (RV32)

1取决于所使用的debug probe 。

2 With PowerTrace III

3 With PowerTrace Serial 2

4 The streaming rate defines the per-second throughput of data that can be transferred on-the-fly to the PC. If the trace-port rate is below the average streaming rate, a practically infinite recording time (limited only by disk space and speed) possible. The peak-rate is possible temporarily and is compensated by the internal memory of the PowerTrace extension.

5  Depends on Whisker plugged to CombiProbe.
